| Main components | Superfine polyester (PET) | Flame retardant grade | F1(DIN 53438)、B1(GB/T 17591-2006) |
Filter Grade | F5、F6、F7、F8、F9(EN779) | Dust capacity | 450g/m2 、500g/m2 、600g/m2 |
Filter object | coarse dust and foreign matters ≥5μm | Temperature resistance | ≤100℃ |
Final resistance | 450Pa(Suggestion) | Temp short peaks | 120℃ |
Average weight efficiency | 90%(ASHRAE52.1-1992) | Moisture resistance (relative humidity) | ≤100% |
Model | Filtration Class | EFF. | Thickness（mm） | Weight (g/㎡) | I.N.P (Pa) | F.N.P (Pa) | Dust capacity（g/m2） | Rated Air flow（m/s) |
RT-HC05 | F5 | 45% | 6±2mm | 240±10 | 18 | 450 | 450 | 1.0 |
RT-HC06 | F6 | 65% | 7±2mm | 270±10 | 22 | 450 | 500 | 1.0 |
RT-HC07 | F7 | 85% | 8±2mm | 300±10 | 26 | 450 | 550 | 1.0 |
RT-HC08 | F8 | 90% | 8±2mm | 340±10 | 32 | 450 | 600 | 1.0 |
