Synthetic Pocket Media with lamianted metal mesh | |||||||||
Model | Filtration Class | Eff. (%) | Filter object | Thickness （mm） | Weight (g/㎡) | I.N.P (Pa) | F.N.P (Pa) | Dust capacity（g/m2） | Material |
RT-MSF04 | G4 | 95% | ≥5μm | 3±1 | 260±10 | 15±2 | 200 | 1 | PE Nonwoven |
RT-MSF05 | M5 | 45% | ≥1μm | 3±1 | 230±10 | 7±2 | 250 | 1 | PE+PP |
RT-MSF06 | M6 | 65% | ≥1μm | 3±1 | 240±10 | 11±2 | 250 | 1 | PE+PP |
RT-MSF07 | F7 | 85% | ≥1μm | 3±1 | 250±10 | 16±2 | 250 | 1 | PE+PP |
RT-MSF08 | F8 | 90% | ≥1μm | 3±1 | 260±10 | 23±2 | 300 | 1 | PE+PP |
RT-MSF09 | F9 | 95% | ≥1μm | 3±1 | 270±10 | 28±2 | 300 | 1 | PE+PP |
Electrostatic media with laminated metal mesh | |||||||||
Model | Filtration Class | Eff. (%) | Filter object | Thickness (mm) | Weight (g/㎡) | I.N.P (Pa) | F.N.P (Pa) | Dust capacity （g/m2） | Material |
RT-ME05 | M5 | 45% | ≥1μm | 1.0±0.2 | 200±10 | 3 | 300 | 1 | Electrostatic Needle-punched Filter Media |
RT-ME06 | M6 | 65% | ≥1μm | 1.1±0.2 | 210±10 | 4 | 300 | 1 | Electrostatic Needle-punched Filter Media |
RT-ME07 | F7 | 85% | ≥1μm | 1.2±0.2 | 230±10 | 6 | 300 | 1 | Electrostatic Needle-punched Filter Media |
RT-ME08 | F8 | 90% | ≥1μm | 1.5±0.2 | 260±10 | 7 | 350 | 1 | Electrostatic Needle-punched Filter Media |
Activated carbon media with laminated metal mesh | |||||||||
Model | Filtration Class | Eff. (%) | Filter object | Thickness (mm) | Weight (g/㎡) | I.N.P (Pa) | Benzene (%) | Deodorization performance (30 minutes) | Material |
RT-MAC | G4 | 45% | ≥5μm | 3±1 | 400±10 | 20 | >90% | >95% | Activated carbon media |
