| Main Material | polyester fibre（PET） | Flammability rating | F1(DIN 53438)、B1(GB/T 17591-2006) |
Filtration class | F5、F6(EN779) | Dust holding capacity | 500g/m2 、550g/m2、600g/m2、650g/m2 |
Filter object | Coarse dust and foreign matter≥1μm | Temperature resistance | 100℃ |
Final resistance | 450Pa(suggestion) | Temp short peak | 120℃ |
Average weight efficiency | 98%(ASHRAE52.1-1992) | Moisture resistance(relative humidity) | 100% |
Model | Filtration Class | Average capture rate | Thickness (mm) | Weight （g/m2） | Dust holding capacity （g/m2） | Rated air velocity (m/s) | I.N.P (Pa) | F.N.P (Pa) | Scrim/Glue |
RT-N600G | M5 | 99% | 22±2 | 600 | 600 | 0.25 | 45 | 450 | Full glue |
RT-N560G | M5 | 98% | 22±2 | 500 | 500 | 0.25 | 40 | 400 | Full glue |
RT-N450G | M5 | 97% | 22±2 | 450 | 450 | 0.25 | 35 | 400 | Surface glue |
RT-N420G | M5 | 95% | 22±2 | 420 | 420 | 0.25 | 30 | 400 | Surface glue |
RT-N300G | M5 | 90% | 22±2 | 260 | 350 | 0.25 | 28 | 400 | without glue |
| Note: other specification can be customized according to requirements. | |||||||||
